Description
Suitable for Multi switch
Super Low Noise 0.1dB! FULL HD /4K
Professional Line – Ultimate Reliability Model!
Universal signal
10.7 ~ 12.75 GHz (LO : 9.75 & 10.6 GHz)
Output frequency: 950 to 2150 MHz.
This Universal Ku band LNB can receive signal from all linear polarized Ku Band Satellites .
Features:
Super Low 0.1dB noise figure.
The lover number the better and the stronger the signal reception!
Light weight. So it won’t make your support arm sag or wobble.
Compact and easy to install.
Ideal solution for offset antennas for both analog and digital satellite signal reception.
Integral feed horn with 40 mm neck.
This LNBF has been tested for excellent performance in Middle East.
|
universal ku band lnb specification |
|||
| input frequency | 10.7-12.75ghz | Supply Voltage | |
| output frequency | 950-2150mhz | Direct Current | Direct Current |
| L.O.frequency | 9.75/10.6ghz | Cross Pol.lsolation | 20 dB(min.) |
| L.O. Frequency Stability | +-1.0 MHz@-40ºC to +70ºC | Operating Temperature | -40ºC to +70ºC |
| Noise Figure | 0.1dB | L.O.Phase Noise | -50dBc/Hz@1KHz -75dBc/Hz@10KHz -95dBc/Hz@100KHz |
| Conversation gain | 60dB | Image Rejection | 45 dB(min.) |
| Gain Flatness | ≤ +/-1.5 dB | Input VSWR | 2.5:1(max) |
| Output Impedance | 75ohms | Output VSWR | 2.0:1(max) |
| Output connector | F-female connector | Relative Humidity | 0%-95% |
